3U Rack Mount Pc
Product Details:
X
Product Description
INTRODUCTION:
The KI-N338B is a very compact 3U chassis with the storage, cooling and functionality,2*8 cm fans blow the motherboard directly to provide the best cooling system.3U design that can provide storage capacity of a 4U, superior cooling and expansions over 1U and 2U chassis
| Features and Benefits: | ||
| Max to 2x5.25"+5x3.5" drivebay | ||
| Washable air filter | ||
| Max support 12" x 9.6" M/B with depth=380mm | ||
| SPECIFICATION | ||
| Dimension (W x H x D) | 19" x 5.25"x 15"/ 482 x 133.3 x380 (mm) | |
| Material Construction | Heavy-duty & Rugged SGCC steel 1.2mm | |
| M/B Size | ATX (12"x9.6") | |
| Expansion | 4 slot full height ATX window | |
| Control & Indicator | 1x Power switch+1x Reset switch 1x LED (Power)+2 x LED (HDD) 2x2.0 USB | |
| Cooling Fans | 2 x 8cm Fan | |
| DriveBay | 2x 5.25 "+5 x 3.5" | |
| Power Supply | Standard PS-2 ATX Power supply 300w~500w | |
| Sliding rail | 20" ball bearing sliding rail (option) | |
| Color | Black or Beige | |
| Operation Temperature | Up to 50C (122, H) | |
| Operation Humidity (Non-condensing) | Up to 90% | |
| Packing Measurement CBF / CBM | 1.8 / 0.05 | |
| Packing N.W / G.W | 6.5KGS / 8KGS | |
